Equipment Division
Glass Thickness Tester
WB-120-8
Brand  : NDK
Product Details
Related product

No

Item

Specification

1

Model

WB-120-8

2

Measurement sample

Glass

3

Measurement performance

1) Measurement point: 8 Point *2set (16ch)

2) Controller: 7” color LCD

3) Measurement program: Data backup / Excel compatible

4) Measurement resolution: 0.1 ㎛

5) Main functions: Four arithmetic operations, MAX,MIN,MAX-MIN, AVG.

4

Probe

1) Moisture-proof structure

2) Length: 96.0mm

3) Measuring pointer diameter: 8mm

4) Measurement load: adjustable (adjusted after sample test)

5) Measurement range: ±2.0mm (max 4.5mm)

6) Repeatability: 1 ㎛

7) Weight: 80g

5

S/W

1) Automatic saving of measurement data

2) Automatic folder creation by date

3) History management by date is possible

4) Statistics processing function
